Kit CB CBI PNI Escort 62 and PNI Extra 48 with Magnet included, ASQ, RF gain

Portable CB station with external antenna adapter and lighter socket + CB antenna with cable and magnet included
€95.30
Availability: In stock
SKU
PNI-HP62-48

Hp62

Multifunctional illuminated screen

The illuminated screen displays the current working mode of the station: the active functions (EMG, LOCK, SC, DW), the frequency band and the number of the selected channel, as well as the strength of the received signal and the transmitted signal.

Portable, small size

Similar to a walkie-talkie, the PNI Escort HP 62 CB station is extremely accessible and convenient to use due to its small dimensions, only 73 x 35 x 92 mm - without the power adapter. Thus, you can place the station in the armrest or in the restricted spaces on the dashboard of any car.

00002

PNI Escort HP 62 portable CB

Multiple functions

Although small in size, the PNI Escort HP 62 is equipped with most of the functions necessary for a CB station, thus satisfying the demands of any user. Functions such as RF Gain (9 levels), SQ (28 levels), Scan, Automatic Squelch (5 levels), Dual Watch or Last channel recall make the station easy to adapt to different communication needs.

Connectivity: BNC connector, 2-pin plug and PL259 plug

The PNI Escort HP 62 CB radio station has a double use: in the car as a mobile station together with the antenna mounted on the body and outside as a portable station by installing a BNC antenna and batteries (optional accessories). The microphone and loudspeaker connections allow the connection of a 2-pin headset with which we can communicate hands-free.

CB radio station PNI Escort HP 62

CB antenna PNI Extra 45 with magnet included SWR 1.0

CB antenna, discreet and efficient

The PNI Extra 48 antenna is among the smallest CB antennas (it is only 45 cm high) and can be mounted both on cars, vans and minibuses. Its small dimensions make it almost imperceptible, easily confusing with the radio antenna. The average reception distance is 10 km.

Anti-noise design

The PNI Extra 48 CB antenna has a special anti-noise design that allows the air to slide around the spike, eliminating wind noise that could disrupt communication.

CB antenna PNI Extra 45 with magnet included SWR 1.0

Video presentation

Kit CB transceiver PNI HP Escort 62 and PNI Extra 48 antenna with magnetic base, ASQ and RF gain

Write Your Own Review
You're reviewing:Kit CB CBI PNI Escort 62 and PNI Extra 48 with Magnet included, ASQ, RF gain
Your Rating
Product identification
Product code PNI-HP62-48
General characteristics of the radio station
Frequency 26.965-27.405 MHz
Emission band type AM-FM
feeding 12 V
Sensitivity (10dB) 0.5uV (AM) 0.25uV (FM)
Speaker audio power 0.5W
Absorbed current 900 mA
Model Portable
Dimensions (W x H x D / Weight) 73 x 35 x 92 mm (without power adapter) / 332 g (including adapter)
Special features Radio station
ASQ - Automatic Squelch Yes, 5 levels
RF Gain Yes, 9 levels
Small Gain Not specified
Emergency channel button 9/19 Yes
Roger Beep Not specified
LCR - the last selected channel Yes
Color screen Yes
SQ - Squelch Yes, 28 levels
General characteristics of the radio antenna
Working frequency 26 - 28 Mhz
Maximum power applied 150 W
Minimum SWR in the center of the band less than 1.2:1
Length 45 cm (magnetic base included) Spike length: 44 cm
Impedance 50 Ohms
Material Fiber glass
Connector type PL259
Cable length (m) 4 m
Weight 193 g
Magnetic base 103 x 66 x 40 mm
The package contains
Radio station antenna Yes
Magnetic base Yes
Radio station microphone Yes
Microphone holder Not
Station mounting support Not
Wired remote control Not
External microphone for handsfree Not
Charger/support for 8 batteries Not
BNC antenna 19 cm Not
Radio station case Not
Support for 6 batteries Not



PNI-HP62-48
Lang Type Name Link
EU Declaration of Conformity Declaration of conformity DE, EN, ES, FR, HU, IT, PL, RO Link
EU10 User manual User manual EU10 Link
