Wireless CB PNI Escort package HP 6500 ASQ + CB PNI ML100 antenna

Be the first to review this product

€78.06

Availability: In stock

SKU

PNI-PACK63

Details

Reduced dimensions Its reduced dimensions (only 110x120x25mm) allow the station to be placed even in very narrow spaces, without having to resort to a real installation, as in the case of a classic CB.
	Emission power 4W The station complies with the legislation in force in Romania harmonized with European standards, having the maximum legal power allowed of 4 W.
FM/AM The PNI Escort HP 6500 CB station allows communication in the FM band, used in Romania, but also in the AM band, when traveling abroad. In addition to the band type, the station also allows the selection of the frequency band, a setting necessary for using the station in other European countries.
	Double squelch, adjustable and automatic digital PNI Escort HP 6500 is improved with a digital automatic system for reducing noise and interference (Digital Automatic Squelch). The dual manual and automatic squelch mode offers 28 and 9 level settings along with the RF Gain function for a finer reception adjustment.
CB antenna performance PNI ML100 The performance of the product is closely related to the technical characteristics of the antenna in ideal conditions of installation and use: SWR <= 1.0, maximum power applied 250 W continuously, impedance 50 Ohms, stainless steel, etc.
	Communication distance The communication distance is another decisive factor in the purchase and use of a CB antenna. Thus, the maximum communication distance of 12 km is achieved in ideal working conditions: calibrated antenna, open field without obstacles, the station with the legally permitted maximum power of 4W and with a standard reception. Any obstacle such as: hills, mountains, buildings, walls can reduce this distance.
Antenna length The length of the antenna is a very important factor that can influence the communication distance. Thus, the longer the antenna, the greater the range of action. The PNI ML100 antenna is 110 cm long (magnetic base included).
	Magnetic base The magnetic base 120/PL in the package is provided with a 4 m cable, enough to place the antenna on the dome, it has a diameter of 125 mm and a strong magnet that gives the antenna stability even at high speeds.

Video presentation
CB PNI ML100 antenna EN

Reviews

Technical specifications

Product identification
Product code	PNI-PACK63
General characteristics of the radio station
Model	Portable
Emission band type	AM-FM
Frequency	26.965-27.405 MHz
channels	40 AM/FM
Speaker audio power	1W
Sensitivity (20dB SINAD)	greater than 1 µV (AM/FM)
Emission power	4 W
Modulation	80 - 90%
feeding	12 V
Consumption	2A maximum
Dimensions / Weight	110 X 120 X 28 / 385 g
Special radio station features
Channel scan	Yes
RF Gain	Yes, 9 levels
Lock the keyboard	Yes
Emergency channel button 9/19	Yes
ASQ adjustable	Yes, 28 levels
SQ - Squelch	Yes
Characteristics of the radio antenna
Working frequency	26 - 28 Mhz
Number of channels	90
Maximum power applied	250 W
Minimum SWR in the center of the band	1.0
Antenna length	100 cm (110 cm with base included)
Working distance	10 km
Impedance	50 Ohms
Material	Stainless steel
Connector type	PL259
Hole diameter	16 mm
Magnetic base included	Yes
Magnetic base diameter	125 mm
Cable length	4 m
The package contains
CB radio station	Yes
CB radio antenna	Yes
Magnetic base	Yes
Plug PL259	Yes
RG58 cable	Yes, 4 m
