SilverCloud YR300 Electromagnetic Yala with hub, right side opening, Fail Secure NO
Fail-secure actuation, normally open | |
In this configuration, the lock opens with an electrical impulse of 12 V 1A 0.5 seconds received from a NO circuit (and closes only after the door or gate has been opened and closed) or manually (the mechanical components ensure opening from the inside even in the case of power cuts). |
|
Opening on the right side | |
| The SilverCloud YR300 applicable electromagnetic lock can be mounted on doors opening on the right side inwards. The recommended thickness of the door is between 35 and 50 mm. |
Compatible with intercom or access control systems | |
The electromagnetic Yala SilverCloud YR300 can be integrated into an access control or intercom system. The Unlock button on the internal unit of the video intercom in your home can unlock the door, thus allowing visitors access inside. |
|
| Product identification | |
| Producer | Silvercloud |
| Product code | PNI-SCYR300 |
| Material | Satin nickel |
| General characteristics | |
| Type yala | Applied |
| Inside opening type | Electrical / Mechanical |
| Supply voltage | 7 - 12V |
| Consumption | 2 - 3.5 A at 12V |
| Actuation type | Fail Secure ( Circuit NO / Normally Open) |
| Compatible with intercom and access control systems | Yes |
| Dimensions/Weight | 125.5 x 101 x 39mm / 1005g |
| Mode of application | Right |
| Operating time | 0.5 s - 3 s at 12V |
| Retention system | Yes, mobile tongue/puppy |
| Lifetime | > 200,000 openings |
| Recommended thickness for the door | 35 - 50 mm |
| Working temperature | -26°C ~ +60°C |
| Package Included | |
| Yala electromagnetic | Yes |
| Opening hub | Yes |
| Opening keys | 3 pcs. |
| Clamping system in the heel | Yes |
| Mounting accessories | |
 PNI-SCYR300 |
|
