SilverCloud YE910 12V stainless steel 12-piece electromagnetic box with double hub and button, Fail Secure NC compatible with access control systems
PNI-SCYE910 - SilverCloud YE910, 12V, stainless steel, double hub and button, Fail Secure NC electromagnetic Yala compatible with access control systems
Fail-secure, NO - Normal Open actuation |
|
|
In this configuration, the lock opens at an electrical impulse of 12V 1A 0.5 seconds provided by a NO circuit (and closes only after the door or gate has been opened and closed) or manually (the mechanical components ensure opening from the inside even in the event of power failures). |
|
Universal opening |
|
|
|
The SilverCloud YE910 can be mounted on doors with opening on the right or left side, inwards or outwards. The recommended thickness of the door is between 35 and 50 mm. |
Compatible with intercom or access control systems |
|
|
The SilverCloud YE910 electromagnetic beam can be integrated into an access control or intercom system. The Unlock button on the internal unit of the video intercom in your home can trigger the unlock of the yala, thus allowing visitors access inside. |
|
Stainless steel |
|
|
|
Guaranteed for more than 200,000 openings, the YE910 electromagnetic beam is made of resistant materials: stainless steel on the outside and brass (hub and latch). |
| Product identification | |
| Producer | Silvercloud |
| Product code | PNI-SCYE910 |
| Material | Stainless steel |
| General features | |
| Type yala | Applied |
| Inside opening type | Electrical / Mechanical |
| Supply voltage | 7 - 12V |
| Consumption | 50 - 60W |
| Drive type | Fail Secure (NO / Normally Open Circuit) |
| Dimensions/Weight | 125 x 98 x 39mm / 1137g |
| Application method | Left/Right |
| Compatible with intercom and access control systems | Yes |
| Operating time | 0.5 s - 3 s at 12V |
| Lifespan | > 200,000 openings |
| Recommended door thickness | 35 - 50mm |
| Working temperature | -26°C ~ +80°C |
| Retention system | Yes, caster type |
| Mechanical unlocking system | Yes |
| Package Included | |
| Electromagnetic yala | Yes |
| Opening hub | Yes |
| Opening keys | 5 pcs. |
| Frame fastening system | Yes |
| Mounting accessories | Yes |
