Switched voltage source PNI ST3.4A 12V 3.4A stabilized for surveillance systems

Stabilized switching voltage source PNI ST10A 230V to 12V 10A stabilized for surveillance systems

Be the first to review this product

Switching voltage source.

€16.62

Availability: In stock

SKU

PNI-ST10A

	Applications The PNI ST10A voltage source can be used in access control systems, video surveillance systems or in any application with consumption less than 10A.
entry The PNI ST10A voltage source is powered by the normal electricity network with a voltage of 230V.
	output PNI ST10A has a 12V output and a maximum capacity of 10A.
Physical characteristics The base plate of the voltage source is protected by a shock-resistant metal case. Due to its small dimensions, it can be easily mounted and hidden in a connection box. It has the dimensions: 160 x 98 x 40 mm.

Video presentation
Stabilized switching voltage source PNI ST10A EN

Technical specifications

Product identification
Producer	PNI
Characteristics
Input voltage	230V AC
Input signal frequency	50-60Hz
Output voltage	2 x 12V
Output current	10A (peak)
Power output	120W
Overload protection	From 105% to 115%
Operating temperature	-26°C ~ +80°C
Dimensions (L x H x W) / Weight	160 x 98 x 40mm / 336g
Efficiency	73%
Short circuit protection	Yes
Cooling fan
The package contains
Power source	Yes

PNI-ST10A

Lang	Type	Name	Link
EU	Declaration of Conformity	Declaratie de conformitate EN, ES, HU, IT, PL, RO	Link
EU10	Declaration of Conformity	Declaration of conformity EU9	Link
EU10	User manual	User manual EU10	Link
