Simple switch with glass PNI SH101 touch, white with LED indicator

White PNI SH101 touch switch with LED indicator with transparent tempered glass front panel and fire-resistant rear case. It can be used at a maximum power of 100W for LED bulbs, and for classic bulbs at a maximum of 200W.

€7.28

Availability: In stock

SKU

PNI-SH101

Details

	Touch screen The industrially designed capacitive touch switch PNI SH101 has a sensitive and fast response. Ultra-low consumption design that offers extra energy savings and environmental protection.
Glass panel The switch has a transparent tempered glass panel with a modern design. It can be touched even with a wet hand without any danger.
	Unique and modern design Unique and modern design of the night light indicator. Ideal for the elderly and children. Installation is done without additional wires being compatible with traditional electrical installations. No need to change the original electronic circuit.
Right for The PNI SH101 single touch switch is suitable for home, offices, hotels and other similar places. Not suitable for factories, CT rooms, magnetic resonance imaging in hospitals or other places with strong electromagnetic interference.
	Compatibility It is compatible with all types of LED bulbs, incandescent lamps, halogen lamps, energy saving lamps, fluorescent lamps with electronic driver.
When the lamp lights up or flashes When the lamp is off but light or flashing, please connect the yellow capacitor in the package between the neutral Null wire and the live one (phase). After this operation the switch will work correctly and the lamp will have no more problems.

Video presentation
Simple switch with glass PNI SH101 touch, white with LED indicator UK

Reviews

Technical specifications

Product identification
Producer	PNI
Product code	PNI-SH101
General characteristics
Supply voltage	170-240VAC
Maximum load supported	200 W
Rated current	max. 10
Frequency
Material	Glass / ABS
Color	White
size	86 X 86 X 34 mm
Weight	103 gr
Moisture	10% - 95%
Working temperature	-10 ~ +60°
Other	- Illuminated buttons - Touch buttons - Glass front
The package contains
Switch	Yes, simple
Condenser	Yes
User manual	Yes
