RigExpert AA-230 ZOOM Bluetooth 0.1-230 MHz Antenna Analyzer
| Antenna analyzerThe RigExpert AA-230 ZOOM is a powerful antenna analyzer designed for testing, checking, adjusting or repairing antennas and antenna feed lines. SWR (Standing Wave Ratio) graph and impedance, as well as Smith chart and polar diagram display are the features keys of this analyzer, which significantly reduce the time required to tune an antenna. |
For radio amateurs or professional useEasy-to-use measurement modes, as well as additional functions, such as connecting to a computer, make the RigExpert AA-230 ZOOM attractive to both professionals and hobbyists. |
|
| Memory function for storing graphicsUsing the RigExpert AA-230, you will quickly check an antenna, you will be able to calibrate it, you will be able to measure and compare the SWR and impedance values before and after an event (rain, storm, etc.), you will be able to measure the parameters of coaxial lines, you will be able to test cables to locate defects. |
Power supply and PC/Smartphone/Tablet connection via USB/BluetoothRigExpert AA-230 can be powered with 3 AA alkaline batteries or with the 3 Ni-MH batteries included in the package. Through the included USB cable or the Bluetooth radio connection, you can connect the analyzer to a computer, Smartphone, Tablet for connection and control from the dedicated AntScope2 software. |
|
| Product identification | |
| Product code | PNI-AA-230BLE |
| Producer | RigExpert |
| Characteristics | |
| Frequency range | 0.1 to 230 MHz |
| Frequency step | 1 kHz resolution |
| Compatible with | 25, 50, 75 and 100 Ohm systems |
| SWR measurement range | 1 - 100 in numerical mode / 1 - 10 in graphic mode |
| SWR display | Numeric and bars |
| Range R and X | 0...10000, -10000...10000 in numerical mode / 0...1000, -1000...1000 in graphic mode |
| RF output | UHF type connector (SO-239) |
| Output signal form | 0.1 to 230 MHz |
| Power output | -10 dBm (at 50 Ohm load) |
| feeding | 4 batteries 1.5V alkaline type AAA |
| Battery life (100% charged) | maximum 4 hours of continuous measurement or maximum 2 days in stand-by mode |
| Screen | Color TFT 320×240px |
| Water resistant keyboard | Yes |
| USB port | Yes, for PC connection and power supply |
| size | 82 x 182 x 32 mm |
| Weight | 236 g |
| Working temperature | 0°C ~ +40°C |
| Package contents | |
| Analyzer | Yes |
| Battery | YES |
| USB cable | Yes |
| N-UHF adapter | Yes |
| Belt pouch | Yes |
| User manual | Yes |
