Relay with PNI CA500LR remote control for controlling 1 or 2 garage doors, gates, barriers, 2 relays, 12V power supply

Remote control

With a wide range of applications, the PNI CA500LR can control garage doors, access gates, elevators, elevators, electromagnetic locks and more. The device includes a transmitter (remote control) and a receiver with 2 independent relays.

Modes of operation

By positioning the jumper on the motherboard, several modes of operation of the two relays can be programmed:

1. manual mode (by pressing the button on the remote control, the corresponding relay will close and open);

2. automatic mode (after releasing the button on the remote control, the corresponding relay returns to the initial state);

3. dual mode (one relay closes and the other relay opens).

Maximum number of remote controls

The PNI CA500LR remote control relay can enroll up to 18 remote controls.

Learning a new remote requires a short press of the learn button. The LED lights up. Press the A button on the remote control. The red LED flashes 3 times then stays on to confirm learning the A button to command the first relay. The red LED stays on. Press the B button on the remote control. The red LED flashes 3 times then turns off to confirm learning. Repeat the procedure for learning additional remote controls.
