President Johnson II ASC CB Radio Kit + PNI ML70 CB Antenna, length 70cm, 26-30MHz, 200W
TXMU667 - Radio station CB President Johnson II ASC 12V-24V with automatic squelch and front speaker
| GENEROUS SCREEN The generously sized LCD screen displays the majority of functions and indicators required for use under normal conditions. Among them we can list: the country standard, the number of the channel used, the functions to reduce the parasites that appear both during the transmission and when it is not being broadcast, the local or Hi Cut function. The lighting of both the display and the buttons is a common feature in the top range that helps the driver, especially at night. The S-meter also present on the LCD screen gives us information regarding the transmission/reception power of the CB radio station. |
POWER The radio station President Johnson II 12 / 24 V ASC complies with the legislation in force in Romania harmonized with European standards, having the maximum legal power allowed of 4 W. |
|
| 40 CHANNELS CB radio station President Johnson II 12 / 24 V ASC corresponds to the latest European CB standards. As a unique option, the station has a switch for changing the modulation type, which will allow you to select the operating mode. |
AUTOMATIC SQUELCH CONTROL The station offers its users the ASQ function, automatic squelch, which lends itself to most reception situations. On FM mode in a certain free channel the noise can be annoying. With the Squelch function you can reduce this noise, but at the same time also the signals that are too weak to be received properly. |
|
| 12-24 V CONVERTERThe CB President Johnson II 12 / 24 V ASC radio station can be mounted both on cars with 12V power supply and on trucks or TIRs with 24V power supply. |
PNI-ML70 - PNI ML70 CB antenna, length 70cm, 26-30MHz, 200W, magnet 145 mm included
| CB antenna performance PNI ML70The performance of the product is closely related to the technical characteristics of the antenna in ideal conditions of installation and use: SWR <= 1.2, maximum applied power 200 W, impedance 50 Ohms, stainless steel, etc. |
Communication distanceThe communication distance is another decisive factor in the purchase and use of a CB antenna. Thus, the maximum communication distance of 9 km is achieved in ideal working conditions: calibrated antenna, open field without obstacles, the station with the legally permitted maximum power of 4W and with a standard reception. Any obstacle such as: hills, mountains, buildings, walls can reduce this distance. |
|
| Antenna lengthThe length of the antenna is a very important factor that can influence the communication distance. Thus, the longer the antenna, the greater the range of action. The PNI ML70 antenna is 70 cm long (magnetic base included). |
Magnetic baseThe PNI 145/PL magnetic base in the package is provided with a 4 m cable, sufficient for placing the antenna on the dome, it has a diameter of 145 mm and a strong magnet that gives the antenna stability even at high speeds. |
|
| Full packageThis kit is ready for assembly with: antenna, magnetic base with cable and plug PL259, Allen key for calibration. All you have to do is mount the antenna on the magnetic base, connect it to a CB radio station and calibrate it to use it at maximum performance. |
TXMU667 - Radio station CB President Johnson II ASC 12V-24V with automatic squelch and front speaker | |
|---|---|
| Product identification | |
| Producer | President |
| Product code | TXMU667 |
| General characteristics | |
| Model | Portable |
| Emission band type | AM/FM |
| channels | 40 |
| Frequency | 26.965 - 27.405 MHz |
| Microphone type (pins) | 6 pins |
| Speaker audio power | 3 W |
| Sensitivity (20dB SINAD) | 0.5 mV – 113 dBm (AM / FM) |
| Audio signal distortion | less than 3% @ 1KHz |
| Emission power | 4 W |
| feeding | 13.2 V / 24 V |
| Absorbed current | 400 mA nominal / 1000 mA max |
| Dimensions (W x H x D / Weight) | 52 x 170 x 150 mm / 1 kg |
| 1DIN assembly | Yes |
| Special features | |
| Dual Watch | Yes |
| Channel scan | Yes |
| ASQ | Yes |
| Emergency channels | Yes |
| Noise filter | NB (Noise Blanker) and ANL (Automatic Noise Limiter) |
| LOC-DX button | Yes |
| and meter | Yes |
| Rear panel connections | |
| Additional speaker connection | Yes |
| The package contains | |
| Radio station | Yes |
| Microphone | Yes |
| Support and screws for holding the radio station | Yes |
| Microphone support and screws | Yes |
| Power cord | Yes |
| User manual | Yes |
PNI-ML70 - PNI ML70 CB antenna, length 70cm, 26-30MHz, 200W, magnet 145 mm included | |
|---|---|
| Product identification | |
| Product code | PNI-ML70 |
| Work tape | ? B |
| Product color (spike) | Black |
| General characteristics | |
| Working frequency | 26 - 28 Mhz |
| Number of channels | |
| Maximum power applied | 200W |
| Minimum SWR in the center of the band | less than 1.2 |
| Length | 70 cm (magnetic base included) |
| Impedance | 50 Ohms |
| Material | Stainless steel |
| Connector type | PL |
| Hole diameter | 16 mm |
| Cable length | 4 m |
| Weight | 800g |
| size | 100 x 18 x 5 cm |
| I earn | 4 dBi |
| Working distance | 8 km |
| Operating temperature | -26°C ~ +80°C |
| The package contains | |
| Radio station antenna | Yes |
| RG58 cable | 4 m |
| Plug PL259 | Yes |
| Magnetic base | 145 mm |
 TXMU667 |
| ||||||||||||||||||||||||
 PNI-ML70 |
|
