PNI AP800D gate automation kit includes motor, photocells, remote control, lamp, 230V develops 1100 N and 800KG sliding gate

Self-supporting gate automation motor

The motor has a power of 350W and can open or close gates with a maximum weight of 800 kg.

The PNI AP800D gate automation kit, which includes this motor, contains all the components necessary for the automation of a self-supporting gate: the motor, the warning lamp, two photocells and mounting accessories.

Local  and remote control

The gate can be opened and closed from the remote control (2 remote controls included) or other access control devices such as access buttons, access keypads, card readers, smart relays with internet control, etc. can be connected.

Obstacle detection and incident prevention

To avoid incidents, you can set the level of sensitivity to obstacle detection: from low to high. If the gate is closing or opening and encounters an obstacle, the engine will stop.

Also, the set of photocells included in the package detects any obstacle that has appeared or is present in the gate opening and automatically stops the motor or the closing of the gate.

Auto-close

You can program the automatic closing of the gate after a certain number of seconds (10, 30 or 60). It is also possible to program the condominium mode that allows simultaneous control from multiple access devices.

In condominium mode, when the gate is open, if the buttons on the remote control or other connected access terminal (access button or access keypad) are pressed, they will not work until the gate is fully open. When the gate is closing, if the buttons on the remote control or other connected access terminal are pressed, the gate will stop and open completely allowing access.

Warnings in assembly

Do not perform welds when:

- it is mounted on the bearing sets (the bearing contact is damaged);

- the motor is mounted (leads to the failure of the board and the wiring on it).
