CB PNI antenna by Sirio ML145

CB PNI antenna by Sirio ML145 with PL thread, length 145 cm and magnet 145 mm included

CB PNI LED 1000 antenna with cable and fixed mount

Folding CB PNI LED 1000 antenna, 80 cm long, with cable and butterfly fixed mount, 26-30 MHz, 300 Watt, illuminates during transmission

CB PNI ML90 antenna 26-30MHz, 71 cm, 150W, wireless, compatible with any PL259 connection

CB antenna PNI ML90, 26-30MHz, 71 cm, 150W, without cable with PL clamp
€14.57
Availability: In stock
SKU
PNI-ML90FC

Antenna CB, PNI, PL, SWR, ML90

Resistant and efficient

The PNI ML90 CB antenna has a length of 71 cm and a communication distance of 8 - 10 km (under ideal conditions of use).

It is perfect for drivers of TIRs, trucks or cars who want a product that ensures good communication in traffic.

The SWR of less than 1.2:1 and the maximum supported power of 150W are essential specifications that recommend this product to the most demanding users.

Choose correctly

When choosing a CB antenna, the following aspects must be taken into account:

  • the method of attaching the antenna (fixed support or magnetic base);
  • antenna length;
  • antenna positioning.

The CB antenna is very important in the station-antenna assembly because the quality of the emitted and received signal depends on it.

The quality of CB PNI antennas is already known by the very low values of the SWR.

Antenna CB, PNI, PL, SWR, ML90

Antenna CB, PNI, PL, SWR, ML90

Compatible PNI accessories

The PNI ML90 CB antenna with ø16 mm thread is compatible with all PL type magnetic bases ( for example: PNI 145/PL ).

PNI also offers a wide range of accessories recommended for threaded antennas:

  • PNI T941 or PNI SPA100 support for mounting the antenna on the trunk;
  • connecting cable PNI T601;
  • PNI SPA110 support for mounting the antenna on the mirror or metal bar;
  • PNI SPA120 support for mirror mounting;
  • PNI SPA130 support for mounting on the tear duct;
  • support PNI L1 and L2.

Video presentation

CB PNI ML90 antenna, 26 30MHz, 71 cm, 150W UK

Write Your Own Review
You're reviewing:CB PNI ML90 antenna 26-30MHz, 71 cm, 150W, wireless, compatible with any PL259 connection
Your Rating
Product identification
Product code PNI-ML90FC
Work tape ? B
Product color (spike) Black
General characteristics
Working frequency 26 - 30 MHz
Maximum power applied 150W
Minimum SWR in the center of the band less than 1.2
Length 71 cm
Impedance 50 Ohms
Material Fiber glass
Connector type PL
Hole diameter 16 mm
Weight 280 gr
size 715 x 21 x 21 mm
Polarization vertically
Working distance 10 km
Magnetic base Does not have
Operating temperature -26°C ~ +80°C
The package contains
Radio station antenna Yes



PNI-ML90FC
