CB PNI Escort HP 9700 USB, ANC, ASQ radio station, 12V / 24V power supply, cigarette lighter plug included
Multi-norm CB radio station
By changing the norm, the procedure is easy to execute with a simple combination of keys, and by changing the modulation (AM/FM) depending on the norm, the CB PNI Escort HP 9700 radio station can be used in several countries in Europe, such as Romania, Italy, Spain, UK, Germany, Poland, etc. Consult the legislation of each country regarding the use of the CB band, the maximum allowed emission power and the need or not to hold a license before using the PNI station.
Noise control functions: SQ, ASQ, RF Gain and ANC
The PNI Escort HP 9700 CB radio station allows the most faithful control over the background noise specific to the CB band. The adjustable SQ function on 28 levels and ASQ on 5 levels allow the user to filter and eliminate noises making communication clearer. The RF Gain function on 9 levels allows control over the reception frequency, reducing distortions. The ANC (Automatic Noise Cancelling) function automatically extracts and cancels the noise level on the reception.
Scan, Lock, EMG and USB port
The PNI Escort HP 9700 is a station that easily meets the basic needs of any CB band user. The channel scan function, key lock and immediate access to emergency channels (9/19) through the dedicated button make the HP 9700 an accessible, intuitive and easy-to-set station. The USB 5V 1.7A connector on the front panel offers the possibility of charging mobile devices.
The RFG/MENU key on the front panel allows direct access to the additional settings menu: setting the RF Gain level, activating/deactivating the ANC function, setting the brightness level and screen contrast.
CB PNI Escort HP 9700 USB, ANC, ASQ radio station, 12V 24V power supply UK
|Product type||CB radio station|
|Emission band type||AM/FM|
|Frequency||26.965 - 27.405 MHz|
|Microphone type (pins)||6 pins|
|Sensitivity (20dB SINAD)||greater than 1 µV AM/FM|
|Emission power||4 W|
|Modulation||70% - 90% (AM) / 1.9KHz (FM)|
|feeding||12 V / 24 V|
|Dimensions (W x H x D / Weight)||115 x 150 x 38 mm / 0.8 kg|
|RF Gain||Yes, 9 levels|
|ASQ||Yes, 5 levels|
|Lock the keyboard||Yes|
|Noise filter||ANC (Automatic Noise Cancelling)|
|Manual squelch||Yes, 28 levels|
|Operating temperature||-26°C ~ +80°C|
|Use, destination||in the car, truck, or at home|
|Rear panel connections|
|Additional speaker connection||Yes|
|Front panel connections|
|The package contains|
|Support and screws for holding the radio station||Yes|
|Microphone support and screws||Yes|
|Cigarette lighter plug||Yes|
